Ventilation Fan Exhaust System Design
Explore the comprehensive features of our ventilation fan exhaust system design tool:
Duct Sizing Parameters: Select your preferred duct sizing parameters with ease. Choose from different duct shapes (e.g., round, rectangular), set maximum velocities, and specify allowable pressure drops to ensure optimal system performance.
Intuitive Drawing: Effortlessly draw and adjust your duct layout and grille locations. The tool simplifies the process of designing complex systems, allowing for quick modifications and accurate system configurations.
Automated Duct and Fan Sizing: The software automatically runs CIBSE-verified calculations for duct dimensions and pressure drops while matching them with the fan duty, ensuring balanced airflow and efficient operation throughout the entire ventilation system.
Comprehensive Exports: Export all necessary calculations to spreadsheets, bill of materials, and detailed drawings in both PDF and CAD formats. Generate professional-grade documents, including system layouts, equipment schedules, and detailed ductwork designs, ready for submission or further editing.
